Bidirectional connection between eAssistant and Autodesk Inventor (shaft, gear, involute spline profile as single part).

The calculation information is saved in the 3D model and is available at any time.

With just one click, the design table with all manufacturing details of involute splines can be placed on the drawing as well.

Involute splines can be created as a 3D Autodesk Inventor part (single part or directly on existing part) on the basis of the calculated data.For serrated and splined shaft connections, the shaft and the hub profile can be generated as native 3D models (single part) based on the calculation.Solid and hollow shafts with an unlimited number of cylindrical and conical shaft segments can be generated.The appearance and size of that table is individually configurable. A simple mouse-click allows to add all necessary manufacturing data of a gear wheel to the drawing.Based on the calculation, straight, helical and spiral bevel gears can be automatically created as a native 3D part in Autodesk Inventor.For this purpose, the user has to specify an offset (increase of the facewidth) or a radius for the cutter or grinding wheel.

During the generation, a tool runout can be developed.

Cylindrical gears can be created as a single part or directly on an existing part.

Based on the calculation, external and internal, spur and helical gears can be generated automatically as a feature-based 3D part in Autodesk Inventor.

It is possible to start all eAssistant calculation modules directly from Autodesk Inventor through an integrated menu.
